Cattleya Hybrid Visualizer
What would this orchid cross look like? SDXL steered by a botanical phenotype engine, for hybrids that take 4-7 years to actually flower.
Part of the Orchid Vision program. A live demo runs as a Hugging Face Space: musharna/orchid-hybrid-visualizer.
Orchid breeding is slow. A Cattleya cross takes roughly four to seven years from pollination to first flowering, and the decision about which cross to attempt is made years before anyone sees the result. Breeders make that call on intuition built from decades of watching parents and their offspring.
The Cattleya Hybrid Visualizer is an attempt to make that intuition explicit and queryable. Given two parent species, it composes a botanically-grounded description of the expected phenotype and renders it, so “what would this cross plausibly look like?” gets an answer before the four-year wait.
The problem
SDXL will produce a beautiful orchid for any prompt you give it. It will not, on its own, produce an orchid that reflects the genetics of the two parents you named. Left alone, the model draws a generic pretty flower and the output tells you nothing.
Most of the work here therefore sits in the layer that decides what to ask for, rather than in the generation itself.
The phenotype engine
Parent traits are blended as pigment chemistry, not colour names. Anthocyanin, carotenoid and co-pigment are modelled as independent biochemical channels. This matters because a magenta Cattleya crossed with a yellow one does not give you an orange Cattleya: the pigment pathways are independent, so you get a magenta-and-yellow flower, often mottled or patterned. A naive RGB blend gets this exactly wrong.
On top of the channel merge:
- 119 species carry trait profiles in
phenotype_db.json. - Dominance overrides (
dominance_rules.json) encode species-specific behaviour that a weighted average would flatten. - Recessive expression is generation-dependent. The threshold relaxes as ancestry dilutes — F1 suppresses recessives hard, F2 admits them at 50%, F3 and beyond at 25% — so a trait hidden in the first generation can surface in the second, as it does in life.
The engine emits a ~77-token description shaped for CLIP’s context window, which is what actually reaches the model.
Generation
- Base model:
stabilityai/stable-diffusion-xl-base-1.0 - LoRA: one ancestry-aware LoRA, applied at an ancestry-weighted scale (not publicly released)
- Hue tokens: small textual-inversion embeddings trained per pigment channel (anthocyanin-red, carotenoid-yellow), so colour can be steered independently of the prose prompt
The published gallery is pre-rendered at seed 42, F1 depth, under the diffusers regime the LoRA was validated against. A live interactive generator (arbitrary parent pairs, warm-colour control, multiple seeds) also exists, but needs ZeroGPU hardware to run in-Space.
The latent map
Each cross is also placed in orchid-clip-v8 embedding space. The two parents sit at the ends of a chord and the predicted F1 at its midpoint. Where a real example of the hybrid exists, it is plotted perpendicular to that chord, and its off-chord distance is what the plot is for.
That offset is the transgressive residual: the part of the real hybrid that is novel beyond both parents rather than a blend of them.
The chord it is measured against replicates on an independent backbone. Across 1,002 registered grexes a hybrid sits nearer its parent midpoint than a shuffled null — cosine 0.910 against 0.730 under orchid-clip-v8, 0.886 against 0.539 under DINOv2 — and its nearest neighbour is one of its parents under both. The residual off that chord is the weaker half of the result: the same evaluation grades it marginal, so read it as a direction worth measuring rather than a settled effect.
Limits
- The parent species reference photos are real and CC-licensed; every generated bloom is a prediction, not a photograph. Nothing here is evidence of what a cross actually produced.
- There is no automated recognition gate on generation: samples are not scored against a per-species prototype and filtered. Output quality rests on the phenotype engine and the LoRA, with a human reviewing the results.
- 119 species is a fraction of Cattleya and its allied genera. Crosses outside that set fall back to weaker trait inference.
